Pool Lift — Safe, Quiet, Battery-Powered Access
Compact, non-rotating design for independent, comfortable pool entry. 24V battery system, waterproof remote, 204 kg capacity, quick 2-hour install.
204 kg / 450 lb
~90 cycles/charge
Self-operated
Waterproof remote
Key Facts
Capacity: 204 kg (450 lb)
Large-diameter cylinder & smooth motion
Large-diameter cylinder & smooth motion
Power: 24V battery
Up to ~90 cycles per charge
Up to ~90 cycles per charge
Self-operated: waterproof handset
Easy 4-button control
Easy 4-button control
Non-rotating, small footprint
Blends with most pool decks
Blends with most pool decks
Where It Fits
Hotels & Resorts
Discrete look, quick install, low maintenance.
Public Pools
Rugged materials resistant to chlorine & UV.
Rehab & Therapy
Smooth out-and-down motion builds confidence.
Schools & Villas
Self-operated with safety belt & anti-slip seat.
Advantages
Safety
- Slip-resistant seating & safety belt
- Emergency Stop system
- Anti-pinch linkage keeps seat level throughout travel
Comfort
- Ergonomic seat with lumbar support
- Adjustable seat height at deck
- Optional headrest & pull-out leg rest
Durability
- Stainless steel with powder-coated finish
- Marine-grade hardware; UV & chemical resistant
- LDPE footrest with non-slip surface
Easy Use
- Waterproof remote, self-operated
- Quiet & smooth performance
- Simple installation & easy removal for storage
Technical Specifications
| Item | Value | Notes |
|---|---|---|
| Capacity | 204 kg (450 lb) | Maximum load |
| Power System | 24V DC rechargeable battery | Charger included |
| Cycles per Charge | ~90 | Typical use |
| Seat Height Adjust | Yes | 1:1 with water depth reach |
| Handset | Waterproof | 4-button control |
| Materials | Stainless steel + powder coat | Marine-grade hardware |
| Seat | Ergonomic with lumbar support | Non-slip surface |
| Footrest | LDPE, non-slip | Durable, impact-resistant |
| Clearances | Pool wall setback 6–36″; water draft up to 12″ | Adapter options available |
| Protection | UV & chemical resistant | Outdoor rated |
| Emergency | Emergency Stop; return-to-up feature | Failsafe return on control fault |
| Installation | Anchor into 600×600 mm concrete pad | No mains power required |
| Operating Temp | -10 to +45 °C |
* Use both metric & imperial units on brochures for export markets.
Options & Accessories
🛟
Headrest
Added neck support (optional).
Added neck support (optional).
🦵
Pull-out Leg Rest
Clears spa walls; adjustable support.
Clears spa walls; adjustable support.
🎛️
Folding Arms
Easy transfer on/off the seat.
Easy transfer on/off the seat.
🔑
Lock & Key
Key lockout when not in use.
Key lockout when not in use.
🔆
Solar Charging
Maintains charge outdoors.
Maintains charge outdoors.
🧳
Protective Cover
For winter/outdoor storage.
For winter/outdoor storage.
🛠️
Maintenance Kit
Cleaning & service essentials.
Cleaning & service essentials.
🚚
Portable Kit
Convert to portable use (bolt-down during operation).
Convert to portable use (bolt-down during operation).
Installation
- Fixes into a 600×600 mm reinforced concrete base via anchor bolts.
- No electrical supply required (24V battery).
- Typical installation time: ~2 hours.
- Anchor template and install guide provided.
Maintenance & Warranty
- Regular anti-corrosion checks & cleaning.
- Battery care & periodic inspection.
- Service logbook recommended for commercial pools.
- 12-month warranty (extended plans available).
Gallery
Fixed vs. Portable Kit
| Feature | Fixed | Portable Kit |
|---|---|---|
| Operation | Bolt-down on anchor | Portable between locations (bolt-down during use) |
| Setup Time | ~2 hours (once) | Quick move; no re-install |
| Best for | Hotels, public pools | Multi-pool sites, seasonal use |
| Storage | Removable for winter | Compact storage |
Site Check & Limitations
Not ideal for hot tubs or pools with high raised walls without an adapter. Share photos and dimensions; custom solutions are available.
Download Center
Frequently Asked Questions
Does the pool lift include a warranty?
Yes, 12-month warranty is included. Extended plans are available.
How is a fixed pool lift installed?
It anchors into a 600×600 mm concrete pad. We supply the anchor template and installation guide.
How long does installation take?
Typically ~2 hours by our technicians.
Do I need an electrical supply?
No. It runs on a 24V removable rechargeable battery.
Can it be used with hot tubs or boats?
In many cases yes, with proper adapters. Share site photos and dimensions.
Is it safe to leave it outdoors in winter?
Yes, with a protective cover. Portable elements can be detached for storage.
